4. Removethehairpincotterfromthehoodproprod
(Fig.0225).
Fig 0225 Belt 001
5. Supportthehoodandremovetheproprod(Fig.
0226).
Fig 0226 Belt 003
6. Usinga1/2”wrench,removethe2lowerheatshield
screws(Fig.0227).
Fig 0227 Belt 002
7. Usinga3/16”Allenwrench,removethe2upperheat
shieldscrews(Fig.0228).
Fig 0228 Belt 004
