ENGINE
4-45TX525 Service Manual Rev. 000
2. Applyengineoiltothe5ywheelmountingbolt
threads(Fig.0241).
Fig 0241 PICT-4850a
3. Securetheywheeltokeepitfromturning.You
candothisbyslidingalengthof5/16”diameterrod
stockinbetweenthefanmountpulleyandfanmount
spacer.Therodstockshouldbeinsertedsoitruns
ontopofthefanmountpulleyscrew.Therodstock
shouldbeatleast16”(40.6cm)longsothatitrests
onthelefthandloaderarmliftcylinder(Fig.0242).
Fig 0242 PICT-4840
4. Using14mmsocket,installthe5oiledboltsto
securetheywheeltothecrankshaft(Fig.0243).
Fig 0243 PICT-4843
5. Torquethe5ywheelmountingboltsto39.8to43.4
ft-lbs.(53.9to58.8Nm)(Fig.0244).
Fig 0244 PICT-4852
