ENGINE
4-46 Rev. 000 TX525 Service Manual
6. Slidetheenginepulleyontothecrankshaft(Fig.
0245).
Fig 0245 PICT-4857
7. Usinga6mmAllensocket,install5boltssecuring
theenginepulleytotheywheel(Fig.0246).
Fig 0246 PICT-4856
8. Torquethe5enginepulleymountingboltsto19+ 2
ft-lbs.(25.7+2.7Nm)(Fig.0247).
Fig 0247 PICT-4858
9. Withthebeltdriveidlerspringunhooked,routethe
drivebeltaroundtheenginepulley(Fig.0248).
Fig 0248 PICT-4862
