Xerox PHASER 6250 Service Manual

3-20 Phaser 6250 Color Laser Printer Service Manual
6
Insert a sheet of paper into the Fuser
Assembly.
Verify the voltage on the Fuser Harness
P138-3 <=> P138-2 is 0VDC.
Go to Step 8. Go to Step 7.
7
Check all pins on the FSR 2 (Fuser)
Harness Assembly PL5.1.10 for continuity.
Go to Step 8. Replace the
Assembly,
Harness FSR 2
PL 5.1.9.
8
Check all pins on the Harness Assembly
Front 1A for continuity.
Go to Step 9]. Replace the
Harness
Assembly Front
1A, PL 13.1.7.
9
If possible print one sheet of paper.
Does the Fuser Motor Turn?
Inspect the gears for damage.
Replace the
gear(s) if
defective.
Go to Step 10.
10
Use service diagnostics to test the Fuser
Motor.
Does the Fuser Motor function correctly?
Replace Engine
Control Board,
page 8-107.
Go to Step 11.
11
Verify the voltage between P 52-1 <=> P
60-2 on the Motor Driver Board is +24
VDC.
Go to Step 12. Replace the
Motor Driver
Board,
page 8-101.
12
Replace the Fuser Drive Assembly
PL 5.1.18. Does the Fuser Motor function
correctly?
Complete Go to Step 13.
13
Check the DRV 1 Harness for continuity. Replace the
Engine Control
Board,
page 8-107.
Replace the
DRV 1 Harness,
PL 13.1.2.
Troubleshooting Procedure (Continued)
Steps Actions and Questions Yes No
