Xerox PHASER 6250 Service Manual

Service Parts Disassembly 8-55
Static Eliminator Assembly (PL 6.1.9)
1. Remove the Front Cover Assembly (page 8-6).
2. Remove 1 screw securing both the ground wire and the Static Eliminator
Assembly (item #2) to the Chute Assembly Out (item #1).
3. Raise the left end up to clear the locator pin and remove the Static Eliminator
Assembly by sliding it to the left.
6250-180
1
2
