Xerox PHASER 6250 Service Manual

Error Messages and Codes 3-61
Out of Paper; Load Tray 1 (MPT) with [size] [type]
■ Remove Tray 1 and inspect the tray cavity of the printer to ensure that it is
free of obstructions or debris.
■ Ensure that the tray is loaded with supported media.
■ Ensure that the media guides are properly adjusted.
■ Reinstall the tray.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
MPT No Paper Sensor, PL 6.1.4 “Paper Feed” on page 10-25
MPT actuator, PL 6.1.37
Troubleshooting Procedure Table
Steps Actions and Questions Yes No
1
Fill Tray 1 (MPT) with paper.
Does the error occur even if Tray 1 is full?
Go to Step 2. Complete.
2
Check the following for evidence of fault
or damage:
MPT No Paper Sensor, PL 6.1.4
MPT actuator, PL 6.1.37
Replace the parts
concerned.
Go to Step 3.
3
Use service diagnostics to test the MPT
No Paper Sensor
Does the Sensor function correctly?
Replace the
Engine Control
Board, page 8-107
Go to Step 4.
4
Replace the MPT No Paper Sensor.
Does the error recur after the sensor is
replaced?
Go to Step 5. Complete.
5
Troubleshoot using the wiring diagram
“Paper Feed” on page 10-25.
Does the problem recur after any
defective parts are replaced?
Replace the
Engine Control
Board, page 8-107
Complete
