3-60 Phaser 6250 Color Laser Printer Service Manual
Tray [3] [4] Paper is Low
■ Remove Tray [3] [4] and ensure that it is at least half full of paper.
■ Inspect the tray for obstructions or defects.
■ Reinstall the tray.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Note
Paper Tray 3 can refer to either the High Capacity Feeder (HCF) or 500-sheet
Feeder. Part list and page references are provided for both units.
In the following procedures, diagnose the part that correlates directly to the Tray
receiving the error.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
Low Paper Sensor, PL
14.5.7 or PL 15.5.7
“Paper Tray 3” on page 10-29 or page 10-33
Low Paper Lever, PL 14.5.8
or PL 15.5.8
“Paper Tray 4” on page 10-30
Troubleshooting Procedures Table
Steps Actions and Questions Yes No
1
Fill the tray with paper.
Does the error occur if the tray is full?
Go to Step 2. Complete
2
Check the following for evidence of fault or
damage:
Low Paper Sensor; PL 14.5.7 or 15.5.7
Low Paper Lever, PL 14.5.8 or 15.5.8
Replace the parts
concerned
Go to Step 3.
3
Use service diagnostics to test the
Tray [3] [4] Low Paper Sensor.
Do the sensor and actuator function
properly?
Replace the
Engine Control
Board,
page 8-107.
Go to Step 4.
4
Does the printer function correctly after
replacing the Circuit Board, Lower Feeder?
Complete Go to Step 5.
5
Troubleshoot using the Paper Tray [3] [4]
wiring diagrams.
Does the printer function correctly after
replacing any defective parts?
Complete Replace the
Engine Control
Board,
page 8-107.
