10-10 Phaser 6250 Color Laser Printer Service Manual
High-Capacity Feeder Plug/Jack Locator Table
P/J No. Connect to... Other end connected to...
81 Circuit Board, Lower Feeder Assembly, Harness HCF-PLUG
82 Circuit Board, Lower Feeder Tray 3 Harness Assembly
83 Circuit Board, Lower Feeder Tray 4 Harness Assembly
84 Circuit Board, Lower Feeder Assembly, HCF Motor Harness
810 Assembly, Harness HCF Main Circuit Board, HCF
821 Switch, Paper Size (T3) Tray 3 Harness Assembly
822 Sensor, No Paper (T3) Tray 3 Harness Assembly
823 Sensor, Low Paper (T3) Tray 3 Harness Assembly
824 Solenoid Feed (Tray 3) Circuit Board, HCF
825 Assembly, Clutch Turn (T3) Circuit Board, HCF
831 Switch, Paper Size (T4) Tray 4 Harness Assembly
832 Sensor, No Paper (Tray 4) Tray 4 Harness Assembly
833 Sensor, Low Paper (T4) Tray 4 Harness Assembly
834 Solenoid Feed (Tray 4) Circuit Board, Lower Feeder
835 Assembly, Clutch Turn (T4) Circuit Board, Lower Feeder
8220 Assembly, Harness No Paper
Sensor
Circuit Board, Lower Feeder
8220 Assembly, Harness No Paper
Sensor
Circuit Board, Lower Feeder
