Parts List 9-41
PL 14.4 Paper Pick Assembly Trays 3 & 4 - Service Parts List Table
ID No. Part Number Qty Name/Description
1. 116-1517-00 1 Paper Pick Assembly, LTA (with 2~5, 7~23)
2. 1 Shaft, Feed 1 (NS)
3. 116-1353-01 2 Paper Pick Roller Kit (2 per order)
4. 116-1354-00 1 Sensor, No Paper, Low Paper
5. 116-1355-00 1 Actuator, No Paper
6. 116-1356-00 1 Actuator, Link (Not included with item 1)
7. 3 Bearing - Metal (NS)
8. 1 Gear, Feed 1 (NS)
9. 1 Spring, Feed 1 (NS)
10. 1 Spring, Feed H (NS)
11. 1 Gear, Feed H2 (NS part of 99)
12. 1 Gear, Feed H1 (NS part of 99)
13. 1 Gear, Feed 2 (NS part of 99)
14. 1 Gear, Idler Feed (NS part of 99)
15. 1 Gear, Idler (NS part of 99)
16. 1 Clutch Stopper (NS)
17. 116-1361-00 1 Feed Solenoid,
18. 116-1362-00 1 Assembly, Turn Clutch
19. 1 Gear, Idler In (NS part of 99)
20. 116-1363-00 1 Assembly, Roll Turn
21. 2 Bearing, Black (NS)
22. 1 Shaft, Feed 2 (NS)
23. 116-1331-00 2 Paper Feed Roller Kit**
**( 2 interchangeable rollers per order)
99. 116-1367-00 1 Paper Feed Gear Kit (with 8, 11~15 and 19)
