General Information 1-11
Printer Specifications
Physical Dimensions and Clearances
Print Engine Dimensions Value
Height: 445 mm (17.52 in.)
Width: 439 cm (17.28 in.)
Depth: 638 mm (25.12 in.)
Weight: Approximately 36.5 kg (80.5 lb.) Print engine
Approximately 56.5 kg (124.5 lb.) with Paper Tray(s) installed
Optional High-Capacity
Feeder Dimensions Value
Height: 336 mm (13.23 in.) Optional Paper Tray Assembly
Width: 439 cm (17.28 in.)
Depth: 563 cm (22.17 in.)
Weight: Approximately 15 kg (33 lb.) no Paper Tray(s) installed
Approximately 20 kg (44 lb.) with Paper Tray(s) installed
Optional 500-sheet
Feeder Dimensions Value
Height: 172 mm (6.77 in.) Optional Paper Tray Assembly
Width: 439 cm (17.28 in.)
Depth: 563 cm (22.17 in.)
Weight: Approximately 7 kg (15.4 lb.) no Paper Tray installed
Approximately 12 kg (26.4 lb.) with Paper Tray installed
Clearance Value
Top: 350 mm (13.78 in.)
Left: 100 mm (3.94 in.)
Right: 150 mm (5.91 in.)
Front: 600 mm (23.62 in.)
Rear: 200 mm (7.87 in.)
Mounting surface level
tolerance:
Within 3 degrees of horizontal with all four feet in contact with
the surface.
