Xerox PHASER 6250 Service Manual

10-25
Paper Feed
ENGINE CONTROL
BOARD
PL12.1.1
P/J13
1
2
3
P139
11
J139
1
P/J133
3
2
1
10 2
9 3
DUP JAM SENSOR
PL6.1.4
PULL UP +3.3VDC
+3.3VDC
SG
DUP JAM SENSED(L)+3.3VDC
P/J13
4
5
6
P139
8
J139
4
P/J134
3
2
1
7 5
6 6
FULL STACK SENSOR
PL6.1.4
PULL UP +3.3VDC
SG
FULL STACK SENSED(H)+3.3VDC
+3.3VDC
P/J13
7
8
9
P139
5
J139
7
P/J135
3
2
1
4 8
3 9
TRAY 1 NO PAPER SENSOR
PL6.1.4
PULL UP +3.3VDC
SG
MSI NO PAPER SENSED(H)+3.3VDC
+3.3VDC
P/J13
10
11
P139
2
J139
10
1 11
P132
2
J132
1
1 2
TRAY 1 FEED
SOLENOID
PL6.1.40
I/L +24VDC
MSI FEED SOL ON(L)+24VDC
Interlock
+24VDC
P/J18
1
2
3
PULL UP +3.3VDC
+3.3VDC
SG
REGI PAPER SENSED(L)+3.3VDC
P/J181
3
2
1
REGI SENSOR
PL9.1.8
P/J18
4
5
I/L +24VDC
REGI CLUTCH ON(L)+24VDC
Interlock
+24VDC
Regi Clutch
CHUTE REGI ASSY
PL9.1.7
P/J19
1
2
I/L +24VDC
MSI TURN CLUTCH ON(L)+24VDC
CLUTCH TURN
(TRAY 1)
PL4.1.9
Interlock
+24VDC
P/J32
3
2
1
+5VDC
OHP PAPER SENSED(L)+3.3VDC
SG
SENSOR OHP
(J35 No Connection)
PL9.1.12
P/J321
1
2
3
+5VDC
6250-320
