Xerox PHASER 6250 Service Manual

3-46 Phaser 6250 Color Laser Printer Service Manual
Install or Reseat Fuser
■ Ensure that the Fuser is fully seated.
■ Ensure that the Fuser latches are in the fully latched position.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
W
arn
i
ng
To avoid the potential of electric shock, ensure the power to the printer is off
and the power cord is disconnected from the wall outlet prior to performing
Step 2 in the following troubleshooting procedure..
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
Fuser Harness (FSR 4), PL 5.1.9 “Fuser Assembly” on page 10-21
Troubleshooting Procedure Table
Steps Actions and Questions Yes No
1
Cycle power to the printer.
Does the error recur?
Go to Step 2. Complete
2
Check the Fuser Assembly for fault or
damage.
Replace the Fuser
Assembly,
PL 8.1.1
Power cycle the
printer after
replacing the Fuser.
Go to Step 3.
3
Does the error recur after replacing the
Fuser Assembly?
Go to Step 4. Complete
4
Check the Fuser Harness (FSR4) for
continuity.
See “Fuser Assembly” on page 10-21.
Go to Step 5. Replace the
Fuser Harness,
FSR 4 PL 5.1.9.
5
Check theFRONT 1A Harness for
continuity.
See “Fuser Assembly” on page 10-21.
Replace the Engine
Control Board,
page 8-107.
Replace the
FRONT 1A
Harness
Assembly,
PL 13.1.7.
