10-12 Phaser 6250 Color Laser Printer Service Manual
500-sheet Feeder Plug/Jack Locator Table
P/J No. Connect to... Other end connected to...
81 Circuit Board, Lower Feeder Assembly, Harness STF-PLUG
82 Circuit Board, Lower Feeder Tray 3 Harness Assembly
83 Circuit Board, Lower Feeder Not connected
84 Circuit Board, Lower Feeder Assembly, STF Motor Harness
810 Assembly, Harness STF Main Circuit Board, STF
821 Switch, Paper Size (T3) Tray 3 Harness Assembly
822 Sensor, No Paper (T3) Tray 3 Harness Assembly
823 Sensor, Low Paper (T3) Tray 3 Harness Assembly
824 Solenoid Feed (Tray 3) Circuit Board, STF
825 Assembly, Clutch Turn (T3) Circuit Board, STF
8220 Assembly, Harness No Paper
Sensor
Circuit Board, Lower Feeder
To Next Page
