Parts List 9-11
PL 3.2 Paper Feed II - FRU Parts List Table
ID No. Part Number Qty Name/Description
1. 116-1340-00 1 Assembly, Harness, Temperature/Humidity
(J231~J2361)
2. 116-1341-00 1 Sensor, Temperature/Humidity
3. 116-1342-00 1 Asssembly, Harness, LTA (HCF) (J210~P810)
4. 116-1343-00 1 Assembly, Paper Size Switch
5. 116-1625-00 4 Printer Feet (4 per order)
6. - - - - - - -
7. 116-1345-00 1 Lever, Low Paper
8. 116-1346-00 1 Indicator, Paper Level
9. 1 Indicator, Holder, Shaft (NS)
10. 116-1348-00 1 Indicator, Guide
11. 1 Indicator, Spring (NS)
12. 1 Indicator, Shaft (NS)
13. 116-1351-00 1 Paper Tray Stopper
To Next Page
