Parts List 9-31
PL 11.1 Frame and Drive Assemblies - Service Parts List Table
ID No. Part Number Qty Name/Description
1. 1 Lever, Plate Left (NS)
2. 116-1471-00 2 Lever, Bracket (1 per order)
3. 116-1472-00 1 Lever, Link , Left
4. 116-1473-00 8 Lever, Drum (1 per order)
5. 116-1474-00 8 Lever, Spring (1 per order)
6. 116-1475-00 1 Link Lever, Right
7. 1 Lever, Plate Right (NS)
8. 116-1476-00 1 Actuator, I/L
9. 116-1477-00 1 Spring, I/L
10. 116-1478-00 2 Press, Gear IDL (1 per order)
11. 116-1479-00 1 Press, Gear Right
12. 116-1480-00 1 Spring, IDT Right
13. 116-1608-00* 1 Assembly, Developer Drive
14. 116-1609-00* 1 Assembly, Main Drive
15. 116-1483-00 1 Registration, Film
16. 116-1484-00 1 Circuit Board, Earth GRND (Ground)
17. 116-1485-00 1 Spring, IDT Left
18. 116-1486-00 1 Press, Gear, Left
98. 116-1610-00 1 Gear Assy, Press R (with 11 and 12)
99. 116-1611-00 1 Gear Assy, Press L (with 17 and 18)
