Parts List 9-43
PL 14.5 High-Capacity Feeder Harness, Board, Motor - Service Parts List Table
ID No. Part Number Qty Name/Description
1. 116-1622-00* 1 Circuit Board, Lower Feeder
2. 116-1519-00 1 Assembly, OPT Feeder Plug
3. 116-1623-00* 1 Assembly, Harness, Tray 3
4. 116-1521-00 1 Assembly, Harness, Tray 4
5. 116-1624-00* 1 Assembly, Drive, Feeder
6. 1 Gear, Idler (NS, part of PL 3.3.99)
7. 116-1354-00 2 Sensor, No Paper, Low Paper (1 per order)
8. 116-1524-00 2 Lever, Low Paper (1 per order)
9. 116-1525-00 Assembly, Indicator
10. 116-1526-00 Assembly, Harness, NPRSJ
To Next Page
