4-76
HANDLEBAR
Removing the handlebar switch and throttle grip
* YAMAHA GREASE “F”
Order Job/Parts to remove Q’ty Remarks
9 Rear brake light switch connector 2 Disconnect. (for XP560E)
10 Rear brake master cylinder holder 1
11 Bracket 1
12 Rear brake lock lever 1
13 Rear brake lock cable 1 Disconnect.
14 Rear brake master cylinder assembly 1
15 Handlebar switch (left) 1
16 Handlebar switch holder 2
17 Handlebar grip 1
FWDFWD
10
9
11
12
13
14
15
17
16
16
3.5 N・m (0.35 kgf・m, 2.6 lb・ft)
3.8 N・m (0.38 kgf・m, 2.8 lb・ft)
3.8 N・m (0.38 kgf・m, 2.8 lb・ft)
3.5 N・m (0.35 kgf・m, 2.6 lb・ft)
10 N・m (1.0 kgf・m, 7.4 lb・ft)
1.8 N・m (0.18 kgf・m, 1.3 lb・ft)
26 N・m (2.6 kgf・m, 19 lb・ft)
26 N・m (2.6 kgf・m, 19 lb・ft)
4.5 N・m (0.45 kgf・m, 3.3 lb・ft)
To Next Page
