9-38
SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
EAS20551
SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
EAS33149
DTC TABLE
DTC Symptom
Fail-safe system
Diagnostic
code
Starting the
engine
Driving the
vehicle
“11,
25_ABS”
Front wheel sensor (intermittent pulses
or no pulses)
——
“12_ABS”
Rear wheel sensor (intermittent pulses or
no pulses)
——
“13,
26_ABS”
Front wheel sensor (abnormal pulse
period)
——
“14,
27_ABS”
Rear wheel sensor (abnormal pulse peri-
od)
——
“15_ABS” Front wheel sensor (open or short circuit)
“16_ABS” Rear wheel sensor (open or short circuit)
“17,
45_ABS”
Front wheel sensor (missing pulses)
“18,
46_ABS”
Rear wheel sensor (missing pulses)
“21_ABS”
Hydraulic unit assembly (defective sole-
noid drive circuit)
——
“24_ABS” Brake light switch or tail/brake light
“30_EVENT”
Latch up detected. Unable Unable D08
“31_ABS”
Hydraulic unit assembly (abnormal ABS
solenoid power supply)
——
“32_ABS” Hydraulic unit assembly (short circuit in
ABS solenoid power supply circuit)
——
“33_ABS”
Hydraulic unit assembly (abnormal ABS
motor power supply)
——
“34_ABS”
Hydraulic unit assembly (short circuit in
ABS motor power supply circuit)
——
“41_ABS”
Front wheel ABS (intermittent wheel
speed pulses or incorrect depressuriza-
tion)
——
“42,
47_ABS”
Rear wheel ABS (intermittent wheel
speed pulses or incorrect depressuriza-
tion)
——
“43_ABS” Front wheel sensor (missing pulses)
“44_ABS” Rear wheel sensor (missing pulses)
“51,
52_ABS”
Vehicle system power supply (voltage
of ABS ECU power supply is high)
(DTC No. 51)
Vehicle system power supply (voltage
of wheel sensor power supply is high)
(DTC No. 52)
——
