6 Adjustments
6.2.2 Tuning-less Levels Setting (Fn200) Procedure
6-16
(5) Parameters Disabled by Tuning-less Function
When the tuning-less function is enabled in the factory settings, the settings of these parameters are not avail-
able: Pn100, Pn101, Pn102, Pn103, Pn104, Pn105
, Pn106, Pn160, Pn139, and Pn408. These gain-related
parameters, however, may become effective depending on the executing conditions of the functions specified
in the following table. For example, if EasyFFT is executed when the tuning-less function is enabled, the set-
tings in Pn100, Pn104, Pn101, Pn10
5, Pn102, Pn106, and Pn103, as well as the manual gain switch setting,
will be enabled, but the settings in Pn408.3, Pn160.0, and Pn139.0 will be not enabled
.
: Parameter enabled
: Parameter disabled
(6) Tuning-less Function Type
The following table shows the types of tuning-less functions for the version of SERVOPACK software.
The software version number of your SERVOPACK can be checked with Fn012.
Parameters Disabled by Tuning-less Function Related Functions and Parameters*
Item Name Pn Number
Force Con-
trol
Easy
FFT
Mechanical
Analysis (Ver-
tical Axis
Mode)
Gain
Speed Loop Gain
2nd Speed Loop Gain
Pn100
Pn104
Speed Loop Integral Time Constant Pn101
2nd Speed Loop Integral Time Constant Pn105
Position Loop Gain
2nd Position Loop Gain
Pn102
Pn106
Mass Ratio Pn103
Advanced
Co
ntrol
Friction Compensation Functio
n Selec-
tion
Pn408.3
Anti-resonance Control Adjustment
Selection
Pn160.0
Gain Switch-
ing
Gain Switching Selec
tion Switch Pn139.0
Software Version* Tuning-less Type Meaning
000A or earlier Tuning-less type 1
000B or later Tuning-less type 2 The level of noise produced is lower than that of Type 1.
Parameter Meaning When Enabled Classification
Pn14F
n.0 Tuning-less type 1
After restart Tuning
n.1[Fac-
tory setting]
Tuning-less type 2
To Next Page
