6 Adjustments
6.5.2 One-parameter Tuning Procedure
6-42
Friction Compensation
This function compensates for changes in the following conditions.
Changes in the viscous resistance of the
lubricant, such as the grease, on the sliding parts of the machine
Changes in the friction resistance resulting from variations
in the machine assembly
Changes in the friction resistance due to aging
Conditions to which friction compensation is applicable depend on the tuning mode. The friction compensa-
tion setting in F408.3 applies when the mode is 0 or 1. Tuning Mode = 2 and Tuning Mode = 3 are adjusted
wi
th the friction compensation function regardless of the friction compensation setting in P408.3.
Feedforward
If Pn140 is set to the factory setting and the tuning mode setting is changed to 2 or 3, the feedforward gain
(Pn109), speed feedforward (V-REF) input, and force feedforward (T-REF) input will be disabled.
Set Pn140.3 to 1 if model following control is used together with the speed feedforward (V-REF) input and
force feedforward
(T-REF) input from the host controller.
Refer to 6.9.2 Force Feedforward and 6.9.3 Speed Feedforward for details.
Tuning Mode = 0 Tuning Mode = 1 Tuning Mode = 2 Tuning Mode = 3
Pn408
n.0
[Factory
setting]
Adjusted without the
friction compensation
fun
ction
Adjusted without the
friction compensation
function
Adjusted with the
fr
iction compensation
function
Adjusted with the
friction compensation
function
n.1
Adjusted with the
friction compensation
function
Adjusted with the
friction compensation
function
Mode
Friction
Compensation
Selecting
Parameter Function When Enabled Classification
Pn140
n.0
[Factory
setting]
Model following control is not used
together with the
speed/force feedforward input.
Immediately Tuning
n.1
Model following control is used together
with the
speed/force feedforward input.
• Model following control is used to make optimum feedforward settings in the SERVO-
PACK when model following control is used with the feedforward function. Therefore,
mo
del following control is not normally used together with either the speed feedfor-
ward (V-REF) input or force feedforward (T-REF) input from the host controller. How-
ever, model following control can be used with th
e speed feedforward (V-REF) input
or force feedforward (T-REF) input if required. An improper feedforward input may
result in overshooting.
