10 Appendix
10-38
Pn535 100 Program JOG Waiting Time Immediately
Pn536 1
Number of Times of Program JOG
Movement
Immediately
Pn550 0 Analog Monitor 1 Offset Voltage Immediately
Pn551 0 Analog Monitor 2 Offset Voltage Immediately
Pn552 100 Analog Monitor Magnification (1) Immediately
Pn553 100 Analog Monitor Magnification (2) Immediately
Pn560 400 Remained Vibration Detection Width Immediately
Pn561 100 Overshoot Detection Level Immediately
Pn580 10 Zero Clamp Level Immediately
Pn581 20 Zero Speed Level Immediately
Pn582 10
Speed Coincidence Signal Output
Width
Immediately
Pn583 10 Brake Reference Output Speed Level Immediately
Pn584 10000 Speed Limit Level at Servo ON Immediately
Pn585 50 Program JOG Movement Speed Immediately
Pn586 0 Motor Running Air-cooling Ratio Immediately
Pn587 0000
Polarity Detection for Absolute Scale
Selection
Immediately
Pn600 0 Regenerative Resistor Capacity Immediately
Pn601 0 Reserved –
(cont’d)
Parameter
Factory
Setting
Name
When
Enabled

YASKAWA SGDV SERVOPACK Specifications

General

Model	SGDV
Type	SERVOPACK
Control Modes	Position, Speed, Torque
Communication Interface	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Protection Rating	IP20
Operating Temperature	0°C to 55°C
Vibration Resistance	5.9 m/s² (0.6G) at 10-60Hz
Shock Resistance	49 m/s² (5G)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Regenerative overload, Encoder error
