YASKAWA V1000 Series Installation & Start-Up Manual

4.5 Test Run
168 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
■ Motor Data for Auto-Tuning
Summary of parameters normally set during Auto-Tuning.
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V
F
O
L
V
P
M
T1-00
Motor
Selection
1/2
Selects which set of motor parameters are set during
Auto-Tuning. If Motor 2 selection (H1- = 16) is not
selected, this parameter will not be displayed.
1: Motor 1 - E1 to E2
2: Motor 2 - E3 to E4
<1>
1, 2 1 A A − 700 407
T1-01
Auto-
Tuning
Mode
Selection
Selects the Auto-Tuning mode.
0: OLV Rotational Auto-Tuning (A1-02 = 2)
2: Terminal resistance only, Stationary Auto-Tuning
(A1-02 = 0, 2)
3: V/f Rotational Auto-Tuning
(A1-02 = 0) Only settings 2 and 3 are available when
using V/f Control. Only setting 2 is available when
using motor 2.
Settings 0 and 2 are available when using OLV Control.
0, 2, 3
0
(“2” in
V/f
mode)
AA− 701 407
T1-02
Motor
Rated
Power
Input the motor nameplate power rating in kW.
HP can be converted to kW using the following:
HP x .746 = kW
For best performance when using OLV select the drive
so that the motor represents 50 to 100% of the drive
rated power.
0.00 to
650.00
0.40
kW
AA− 702 407
T1-03
<2>
Motor
Rated
Vo l t a g e
Set the motor base voltage according to the information
printed on the motor nameplate.
Use the voltage associated with the base frequency of
the motor.
0.0 to
255.5
200.0
V
AA− 703 407
T1-04
Motor
Rated
Current
Enter the motor-rated current.
For best performance when using OLV select the drive
so that the motor represents 50 to 100% of the drive
rated current.
Enter the current required at base speed for motors with
extended speed ranges.
10 to
200% of
drive
rated
current
<3> AA− 704 407
T1-05
<2>
Motor
Base
Frequency
Enter the motor base frequency as specified on the
motor nameplate.
Enter the motor base frequency for extended speed
range motors.
0.0 to
400.0
60.0
Hz
AA− 705 407
T1-06
Number
of Motor
Poles
Enter the number of motor poles as indicated on the
motor nameplate.
2 to 48 4 A A − 706 407

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
