5.6 Alarm Detection
226 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
Cause Possible Solutions
Minor Fault
Output
(H2- = 10)
Communication protocol is
incompatible.
• Check the H5 parameter settings as well as the protocol
setting in the controller.
• Ensure settings are compatible.
YES
The CE detection time (H5-09) is set
shorter than the time required for a
communication cycle to take place.
• Check the PLC.
• Change the software settings in the PLC.
• Set a longer CE detection time (H5-09).
YES
The PLC software settings are not
compatible or there is a hardware
problem.
• Check the PLC.
• Remove the cause of the error on the controller side.
YES
Communications cable is
disconnected or damaged.
• Check the connector for a signal flowing through the
cable.
• Replace the communications cable.
YES
A data error occurred due to noise.
• Check the various options available to minimize the
effects of noise.
• Counteract noise in the control circuit wiring, main circuit
lines and ground wiring.
• Reduce noise on the controller side.
• If the disturbance is caused by switching magnetic
contactors or other equipment, use surge absorbers on
these devices.
• Use cables recommended by Yaskawa or another type of
shielded line. The shield should be grounded on the
controller side or on the drive input power side.
• Separate all wiring for communications devices from
drive input power lines. Install a noise filter to the input
side of the drive input power.
YES
LED Operator Display Minor Fault Name
dEv
Speed Deviation (for Simple V/f with PG)
According to the pulse input (RP), the speed deviation is greater than the
setting in F1-10 for a time longer than the setting in F1-11.
Cause Possible Solutions
Minor Fault
Output
(H2- = 10)
Load is too heavy Reduce the load. YES
Acceleration and deceleration times
are set too short.
Increase the acceleration and deceleration times (C1-01
through C1-08).
YES
The load is locked up. Check the machine. YES
Parameter settings are inappropriate. Check the settings of parameters F1-10 and F1-11. YES
The motor brake engaged. Ensure the brake releases properly. YES

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
