YASKAWA V1000 Series Installation & Start-Up Manual

7.4 Installing Peripheral Devices
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 299
Peripheral Devices & Options
7
Figure 7.4
Figure 7.4 Input-Side Noise Filter (Single-Phase 200 V)
Figure 7.5
Figure 7.5 Input-Side Noise Filter (Three-Phase 200/400 V)
A–Power supply C–Drive
B – Input-side noise filter
Model: LNFD-
D – Other control device
A–Power supply C–Drive
B – Input-side noise filter
Model: LNFD-
D – Other control device
BC
D
A
R/L1
1
2
3
4
E
MCCB
MCCB
S/L2
C
D
A
B
R/L1
U
V
W
R
S
T
E
MCCB
MCCB
S/L2
T/L3

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
