B.2 Parameter Table
336 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
b1-07
Local/Remote Run
Selection
Determines how the drive will interlock when
the source of the run command switches from
LOCAL to REMOTE. Note that one of the H1
parameters be set to 2 in order to use this
function.
0: Cycle External RUN - If the run command is
closed when switching from local mode to
remote mode, the drive will not run. The run
command must first be shut off and then
entered again in order to operate the motor.
1: Accept External Run - If the run command is
closed when switching from local mode to
remote mode, the drive will run.
0,1 0 A A A 186 —
b1-08
Run Command
Selection while in
Programming Mode
0: Disabled - Run command accepted only in
the operation menu.
1: Enabled - Run command accepted in all
menus.
0 to 2 0 A A A 187 —
b1-14 Phase Order Selection
Sets the phase order for drive output terminals
U/T1, V/T2 and W/T3.
0: Standard
1: Switch phase order
0,1 0 A A A 1C3 —
b1-15
Frequency
Reference 2
Selects the frequency reference input source.
0: Operator - Digital preset speed U1-01 or
d1-01 to d1-17.
1: Terminals - Analog input terminal A1 (or
terminal A2 based on parameter H3-09).
2: Serial Com - Modbus RS-422/485 terminals
R+, R-, S+ and S-.
3: Option PCB
4: Pulse Input (Terminal RP)
0 to 4 0 A A A 1C4 —
b1-16
Run Command Source
2
Selects the run command input source.
0: Operator - RUN and STOP keys on the
digital operator.
1: Terminals - Contact closure on terminals S1
or S2.
2: Serial Com - Modbus RS-422/485 terminals
R+, R-, S+ and S-.
3: Option PCB
0 to 3 0 A A A 1C5 —
b1-17
Run Command at
Power Up
Configures the run command at drive
power-up.
0: No run command issued at power up
1: Run command given when power is switched
on
0,1 0 A A A 1C6 —
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
O
LV
P
M
