YASKAWA V1000 Series Installation & Start-Up Manual

2.1 Section Safety
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 35
Mechanical Installation
2
NOTICE
Observe proper electrostatic discharge (ESD) procedures when
handling the drive.
Failure to comply could result in ESD damage to the drive circuitry.
Prevent foreign matter such as metal shavings or wire clippings
from falling into the drive during drive installation and project
construction.
Failure to comply could result in damage to the drive.
Place a temporary cover over the top during installation. Be sure to
remove the temporary cover before start-up, as the cover will
reduce ventilation and cause the unit to overheat.
It may be difficult to perform maintenance on the cooling fans
of drives installed in a vertical row inside an enclosure.
Ensure adequate spacing at the top of the drive to perform cooling
fan replacement when required.
Operating the drive in the low-speed range diminishes the
cooling effects, increases motor temperature, and may lead to
motor damage by overheating.
Reduce the motor torque in the low-speed range whenever using a
non-Yaskawa motor. If 100% torque is required continuously at low
speed, consider using a special drive or vector motor. Select a motor
that is compatible with the required load torque and operating speed
range.
Do not operate motors above the maximum rated RPM.
Failure to comply may lead to bearing or other mechanical motor
failures.

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
