YASKAWA V1000 Series Installation & Start-Up Manual

B.2 Parameter Table
364 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
E5: PM Motor Parameters
E5-01
<25>
Motor Code
Selection (for
PM motor)
Enter the Yaskawa motor code for the motor
being used. Various motor parameters are
automatically set based on the value of this
parameter.
Note: Set to FFFF when using a specialized
or custom motor. For all other motors:
Each time this parameter is set, all motor
parameters are re-initialized to factory
settings. The user should refrain from setting
this parameter more than once.
0000 to
FFFF
<12> <
38>
−−S 329 122
E5-02
<25>
Motor Rated
Capacity (for
PM motor)
Sets the rated capacity of the motor.
0.40 to
18.5
<10> −−S 32A 122
E5-03
Motor Rated
Current (for
PM motor)
Sets the motor rated current in amps.
10 to
200% of
drive
rated
current
<27>
<4> −−S 32B 122
E5-04
<25>
Motor Poles
(for PM
motor)
Sets the number of motor poles. 2 to 48
<10> −−S 32C 122
E5-05
<25>
Motor
Armature
Resistance (for
PM motor)
Set the resistance for each motor phase in
units of 0.001 Ω.
0.000 to
65.000
<10> −−S 32D 122
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
O
L
V
P
M
0000
0: Pico motor
(SMRA series)
1: Derated torque
IPM motor
(SSR1 series)
2: Constant torque
IPM motor
(SST4 series)
0: 1800 r/min
series
1: 3600 r/min
series
2: 1750 r/min
series
3: 1450 r/min
series
4: 1150 r/min
series
F: Custom motor
Motor voltage
class and
capacity

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
