B.2 Parameter Table
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 413
Parameter List
B
U2-13
Drive Operation
Status at Previous
Fault
Displays the operation status of the drive at
the previous fault. Displays the same status
displayed in U1-12.
No signal
output
available
–AAA8C
U2-14
Cumulative Operation
Time at Previous
Fault
Displays the cumulative operation time at the
previous fault.
No signal
output
available
1 H A A A 8D
U2-15
Soft Starter Speed
Reference at Previous
Fault
Displays the speed reference for the soft
starter at the previous fault. Displays the
same status displayed in U1-15.
No signal
output
available
0.01
%
AAA 7E0
U2-16
Motor q-Axis Current
at Previous Fault
Displays the q-axis current for the motor at
the previous fault. Displays the same status
displayed in U6-02.
No signal
output
available
0.10
%
− A A 7E1
U2-17
Motor d-Axis Current
at Previous Fault
Displays the d-axis current for the motor at
the previous fault. Displays the same status
displayed in U6-03.
No signal
output
available
0.10
%
− A A 7E2
U3: Fault History
Use U3 parameters to display fault data.
U3-01 Most Recent Fault Displays the most recent fault.
No signal
output
available
–AAA
90
(800)
U3-02
2nd Most Recent
Fault
Displays the second most recent fault.
No signal
output
available
–AAA
91
(801)
U3-03 3rd Most Recent Fault Displays the third most recent fault.
No signal
output
available
–AAA
92
(802)
U3-04 4th Most Recent Fault Displays the fourth most recent fault.
No signal
output
available
–AAA
93
(803)
U3-05 5th Most Recent Fault Displays the fifth most recent fault.
No signal
output
available
– A A A 804
U3-06 6th Most Recent Fault Displays the sixth most recent fault.
No signal
output
available
– A A A 805
U3-07 7th Most Recent Fault Displays the seventh most recent fault.
No signal
output
available
– A A A 806
U3-08 8th Most Recent Fault Displays the eighth most recent fault.
No signal
output
available
– A A A 807
No. Name Description Range Def.
Control
Mode
Addr.
Hex
V/
f
O
L
V
P
M

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
