B.2 Parameter Table
412 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
U2-03
Frequency Reference
at Previous Fault
Displays the frequency reference at the
previous fault.
No signal
output avail.
0.01
Hz
AAA 82
U2-04
Output Frequency at
Previous Fault
Displays the output frequency at the previous
fault.
No signal
output avail.
0.01
Hz
AAA 83
U2-05
Output Current at
Previous Fault
Displays the output current at the previous
fault.
No signal
output avail.
AAA 84
U2-06
Motor Speed at
Previous Fault
Displays the motor speed at the previous
fault.
No signal
output avail.
0.01
Hz
A 85
U2-07
Output Voltage at
Previous Fault
Displays the output voltage at the previous
fault.
No signal
output avail.
0.1
V
AAA 86
U2-08
DC Bus Voltage at
Previous Fault
Displays the DC bus voltage at the previous
fault.
No signal
output avail.
1 V A A A 87
U2-09
Output Power at
Previous Fault
Displays the output power at the previous
fault.
No signal
output avail.
0.1
kW
AAA 88
U2-10
Torque Reference at
Previous Fault
Displays the torque reference at the previous
fault.
No signal
output avail.
0.1
%
−Α− 89
U2-11
Input Terminal Status
at Previous Fault
Information on previous faults is displayed:
No signal
output avail.
–AAA8A
U2-12
Output Terminal
Status at Previous
Fault
Displays the output status at the previous
fault. Displays the same status displayed in
U1-11.
No signal
output
available
–AAA8B
No. Name Description Range Def.
Control
Mode
Addr.
Hex
V/
f
O
L
V
P
M
U1-09
=
0000000
1: FWD run
command
(terminal S1
enabled)
1: REV run
command
(terminal S2
enabled)
1:Multi-Function
Digital Input 1
(terminal S3
enabled)
1:Multi-Function
Digital Input 2
(terminal S4
enabled)
1:Multi-Function
Digital Input 3
(terminal S5
enabled)
1:Multi-Function
Digital Input 4
(terminal S6
enabled)
1:Multi-Function
Digital Input 5
(terminal S7
enabled)
