C.1 MEMOBUS/Modbus Basic Set-Up
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 433
Network
Communications
C
H5-02
Communication
Speed
Selection
Serial Baud Rate
Selects the baud rate for MEMOBUS/Modbus terminals R+,
R-, S+ and S-. Cycle power for the setting to take effect.
0: 1200 bps
1: 2400 bps
2: 4800 bps
3: 9600 bps
4: 19200 bps
5: 38400 bps
6: 57600 bps
7: 76800 bps
8: 115200 bps
0 to 4 3
H5-03
Communication
Parity
Selection
Serial Com Sel
Selects the communication parity for MEMOBUS/Modbus
terminals R+, R-, S+ and
S-. Cycle power for the setting to take effect.
0: No parity
1: Even parity
2: Odd parity
0 to 2 0
H5-04
Stopping Method
After
Communication
Error
Serial Fault Sel
Selects the stopping method when a communication time-out
fault (CE) is detected.
0: Ramp to stop
1: Coast to stop
2: Fast-stop
3: Alarm only
0 to 3 3
H5-05
Communication
Fault
Detection Selection
Serial Flt Dtct
Enables or disables the communications time-out fault (CE).
0: Disabled - A communication loss will not cause a
communication fault.
1: Enabled - If communication is lost for more than two
seconds, a CE fault will occur.
0 to 10 1
H5-06
Drive Transmit Wait
Time
Transmit WaitTIM
Set the delay time from when the drive receives data to when
the drive sends data.
5 to 65 5ms
H5-07
RTS Control
Selection
RTS Control Sel
Enables or disables "request to send" (RTS) control:
0: Disabled - RTS is always on.
1: Enabled - RTS turns on only when sending.
0 to 1 1
Parameter
No.
Parameter Name
Digital Operator
Display
Description
Setting
Range
Factory
Setting
