H1 Multi-Function Digital Input Selections
H1-oo
Setting
Function Description
Control
Mode
Pg.
V/
f
O
L
V
P
M
12 Forward Jog Closed: Runs forward at the Jog Frequency d1-17. O O O 180
13 Reverse Jog Closed: Runs reverse at the Jog Frequency d1-17. O O O 180
14 Fault Reset
Closed: Resets faults if the cause is cleared and the Run command is
removed.
O O O 180
15 Fast-Stop (N.O.)
Closed: Decelerates at the Fast-Stop time C1-09.
To restart the Fast-Stop input must be released and Run must be cycled.
O O O 180
16 Motor 2 Selection
Open: Motor 1 (E1-oo, E2-oo)
Closed: Motor 2 (E3-oo, E4-oo)
O O O 181
17 Fast-stop (N.C.) Open: Decelerates according to C1-09 (Fast-stop Time) O O O 180
18 Timer Function Input
Set the timer delay using parameters b4-01 and b4-02.
Ensure this function is set in conjunction with the multi-function output
timer (H2-oo = 12).
O O O 181
19 PID Disable Closed: PID control disabled O O O 181
1A Accel/Decel Time Selection 2 Switches Accel/Decel times. O O O 181
1B Program Lockout
Open: Parameters can not be edited. (except U1-01 if reference source is
set for operator)
Closed: Parameters may be edited and saved.
O O O 181
1E Reference Sample Hold
Closed: Samples the analog frequency reference and operates the drive
at that speed.
O O O 181
20 to 2F External Fault
20: N.O., Always Detected, Ramp To Stop
21: N.C., Always Detected, Ramp To Stop
22: N.O., During Run, Ramp To Stop
23: N.C., During Run, Ramp To Stop
24: N.O., Always Detected, Coast To Stop
25: N.C., Always Detected, Coast To Stop
26: N.O., During Run, Coast To Stop
27: N.C., During Run, Coast To Stop
28: N.O., Always Detected, Fast-stop
29: N.C., Always Detected, Fast-stop
2A: N.O., During Run, Fast-stop
2B: N.C., During Run, Fast-stop
2C: N.O., Always Detected, Alarm Only (continue running)
2D: N.C., Always Detected, Alarm Only (continue running)
2E: N.O., During Run, Alarm Only (continue running)
2F: N.C., During Run, Alarm Only (continue running)
O O O 182
30 PID Integral Reset Closed: Resets the PID control integral value. O O O 182
31 PID Integral Hold Closed: Maintains the current PID control integral value. O O O 183
32 Multi-Step Speed Reference 4 Used to select Multi-Step Speeds set in d1-01 to d1-16 O O O 183
34 PID Soft Starter Closed: Disables the PID soft starter b5-17. O O O 183
35 PID Input Switch Closed: Inverses the PID input signal O O O 183
40
Forward Run Command (2-Wire
sequence)
Open: Stop
Closed: Forward run
Note: Can not be set together with Settings 42 or 43.
O O O 183
41
Reverse Run Command (2-Wire
sequence)
Open: Stop
Closed: Reverse run
Note: Can not be set together with Settings 42 or 43.
O O O 183
42 Run Command (2-Wire sequence 2)
Open: Stop
Closed: Run
Note: Can not be set together with Settings 40 or 41.
O O O 183
43
FWD/REV Command (2-Wire
sequence 2)
Open: Forward
Closed: Reverse
Note: Can not be set together with Settings 40 or 41.
O O O 183
44 Offset Frequency 1 Addition Closed: Adds d7-01 to the frequency reference. O O O 183
45 Offset Frequency 2 Addition Closed: Adds d7-02 to the frequency reference. O O O 183
46 Offset Frequency 3 Addition Closed: Adds d7-03 to the frequency reference. O O O 183
47
<1>
Node Setup Closed: Node setup for SI-S3/V enabled. O O O 183
60 DC Injection Braking Command Closed: Triggers DC Injection Braking (b2-02) O O - 183
61 External Search Command 1
Closed: Activates Current Detection Speed Search from the max. output
frequency
(E1-04) if b3-01 = 0. Activates Speed
Estimation Type Speed
search if b3-01 = 0.
O O O 184
B.2 Parameter Table
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
351
B
Parameter List
