Agilent Technologies 5DX Service Guide

5-48 Panel Handling Subsystem
Digital I/O Assembly 5DX Series 3
SMEMA GBO -
Panel Passed
SMT Communication:
Front Panel Signal GPO
Good Panel Out is
False/True
The panel the
5DX is
sending has
passed
inspection.
The panel the
5DX is
sending has
failed
inspection.
17
Enable Green
Beacon
Lights/Laser: Status
Beacon Green is Off/On
Turn on the
green lamp.
Turn off the
green lamp.
18
Enable Red
Beacon
Lights/Laser: Status
Beacon Red is Off/On
Turn on the
red lamp.
Turn off the
red lamp.
19
Enable Yellow
Beacon
Lights/Laser: Status
Beacon Yellow is
Off/On
Turn on the
yellow lamp.
Turn off the
yellow lamp.
20
Enable Blue
Beacon
Lights/Laser: Status
Beacon Blue is Off/On
Turn on the
blue lamp.
Turn off the
blue lamp.
21
Enable Buzzer Lights/Laser: Status
Beacon Buzzer is
Off/On
Turn on the
buzzer.
Turn off the
buzzer.
22
Enable Laser
Camera Lights
Lights/Laser: Laser
View Camera Lights are
Off/On
Turn on the
laser camera
light(s).
Turn off the
laser camera
light(s).
24
Reverse Belt
Direction- K1
Panel Transport: Belt
Direction is
Forward/Reverse
Set the belt
direction to
reversed.
Set the belt
direction to
forward.
25
Enable XYZ
Stage Belts - K2
Panel Transport: XYZ
Stage Belts are Off/On
Turn on the
XYZ Stage
Belts.
Turn off the
XYZ Stage
Belts.
26
SMEMA UPO -
Untested Panel
Output
SMT Communication:
Front Panel Signal UPO
Untested Panel Out is
False/True
The panel the
5DX is
sending has
not been
inspected.
The panel the
5DX is
sending has
been
inspected.
29
Enable View
Camera Lights
Lights/Laser: Panel
View Camera Lights are
Off/On
Turn on the
panel view
lights.
Turn off the
panel view
lights.
30
Table 5-8: Output Direct Current Relay Assignments
Description of
Output
Hardware Status and
Control
LED ON
Indicates
LED OFF
Indicates
Digit
al I/O
Bit
