4-18 Power Subsystem
X-ray High Voltage Power Supply 5DX Series 3
X-ray High Voltage Power Supply
The X-ray High Voltage Power Supply provides -160 kilovolts dc of conditioned
power required to operate the X-ray Tube and +15 volts dc and -15 volts dc for the
X-ray Tube Electronics. The X-ray High Voltage Power Supply also provides
software controlled monitoring facilities, necessary to maintain a stable electron
beam for X-ray Laminography. The X-ray High Voltage Power Supply is shown in
Figure 4-10. Figure 4-11 shows the connectors for the X-ray High Voltage Power
Supply.
Figure 4-10: X-ray High Voltage Power Supply
WA R N I NG There are high voltages inside of the X-ray High Voltage Power Supply and
running through the High Voltage Cable. There are no User serviceable parts
inside of the X-ray High Voltage Power Supply. Do Not attempt to open or
otherwise service this item. Do Not remove the High Voltage Cable.
X-ray High Voltage
Power Supply
X-ray Tube
Assembly
To Next Page
