Agilent 5DX Service Guide 10-9
5DX Series 3 General Maintenance
Check X-ray High Voltage Power Supply Status
Maintenance Frequency: Monthly
Estimated Time: Ten minutes
Required Items:
Printer
Prerequisite:
None
Special Notes:
Each X-ray Tube exhibits unique filament characteristics, therefore, filament
readings are incomparable to specific predefined values. In order to provide an
accurate assessment of the X-ray Tube’s status, it is important to maintain a
System Log book. Each month, the screen printout obtained during this PM
procedure should be inserted into the System Log book.
Information:
None
Attention
The Anode (kilovolts), Cathode Current, Bleeder Current, and Drive
Current should be within ±2% of the values displayed in
Figure 10-2.
127(
The purpose of this procedure is to monitor the X-ray High Voltage
Power Supply in order to determine if changes have occurred in any
of the parameters, thereby indicating a possible failure.
