Agilent Technologies 5DX - Internal Manifold

Agilent 5DX Service Guide 6-7
5DX Series 3 Pneumatic Subsystem Components
Internal Manifold
There is a stage air controller located near the front left area of the stage. It controls
the left and right board stops and board clamps. It is shown in Figure 6-3. The
right and left board stops are controlled by the outer outlets and the board clamp by
the center outlet. The top air fitting in each case is for open and the lower fitting is
for close.
Each of the three barriers have their own air valves located near the barrier
position.
Figure 6-3: Stage Air Controller
/HIW%RDUG6WRS%RDUG&ODPS
2SHQ
&ORVH
)URP0DLQ
0DQLIROG2XWOHW

5LJKW%RDUG6WRS
