2-14 Safety Summary
Laser Safety 5DX Series 3
Laser Safety
The 5DX System uses a solid-state laser to perform a Surface Map of the panel.
This laser has an output of less than 5 mW (milliwatt) at 780 nm (nanometers, or
10-9 meters). Because this laser is capable of causing optical (eye) damage, it is
rated as a class IIIB laser subsystem. The laser operation is linked to the Safety
Interlocks, such that it cannot operate with the access panels open. This effectively
renders the 5DX System a Class I laser product (inherently safe).
Additional Information
WA R N I NG The 5DX System contains a class IIIB laser subsystem. The laser is capable
of causing optical (eye) damage. Do not attempt to defeat any Safety
Interlock. Do not attempt to operate the laser with the access panels open.
127(
The recommendations presented are not intended to be used in lieu
of any government regulations of applicable jurisdiction, but, are
designed to serve only as a guide to basic safety and the operation
of the 5DX Structural Process Test System.
127(
Replacement or repair of the X-ray Tube Assembly, the X-ray Image
Camera, or related system internal assemblies may be made only by
Agilent authorized personnel or individuals who have received
proper training and are certified by Agilent.
