Agilent Technologies 5DX Service Guide

Agilent 5DX Service Guide 6-5
5DX Series 3 Pneumatic Subsystem Components
The Pneumatic Regulator and Filter Assembly is outfitted with an Emergency Stop
solenoid, which immediately stops the operation of the pneumatically controlled
assemblies when either of the Emergency Stop Buttons are pressed.
Figure 6-1: Pneumatic Gauge, Regulator and Filter Assemblies
Automatically
Purged Filter
Trap
Assembly
with Metal
1 160
+
Emergency
Stop Solenoid
Connection
Pressure
Regulator
Pressure
Gauge
(0-160
Emergency
Stop Exhaust
(Air Dump)
Air (Out)
Contaminant Blow Out
1
1
6
0
+
Maximum Operating
Pressure Not to
Exceed
7.7 Kgf/cm
2
(110 psi)
