9-4 System Controller

Expansion Chassis 5DX Series 3

Figure 9-1: Expansion Chassis Rear View

The specific slots have the following boards in them:

1. Receive

2. Digital Frame Grabber 1

3. Digital Frame Grabber 2

4. Analog Frame Grabber

5. Interface Card Cable

6. Interface Card

7. Modem

8. Motion Controller PCI # 1

9. Motion Controller PCI # 2

10. Analog I/O cable

11. Digital I/O 1 cable

12. Digital I/O 2 cable

123456789101112

Slot numbers
