Agilent 5DX Service Guide 4-11
5DX Series 3 Wiring Diagrams
Figure 4-7 shows the wiring input to the E1135C PDU and the outlet wiring for
the mobile workstation table and the expansion chassis.
Table 4-1: Power Options for 3 Phase Wye or Delta (no neutral)
POWER
OPTION
Volts AC FLA Phase Freq.
0ED 200 19 3 check country code
0EF 208 19 3 check country code
05D 220 19 3 check country code
05C 220 19 3 check country code
05H 230 19 3 check country code
0E6 240 19 3 check country code
Table 4-2: Power Options for 3 Phase Wye (with neutral)
POWER
OPTION
Volts AC FLA Phase Freq.
0E5 220/308 10 3 50
05L 230/400 10 3 50
0E7 240/415 10 3 50
