Allen-Bradley E300 User Manual

580 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 10 EtherNet/IP Communication
4. You are prompted whether you would like to upload the configuration
settings from the E300 relay. Press Upload to read the configuration
settings from the E300 relay.
5. If the upload is successful, a display appears that indicates the success of
this command. Press OK to continue.
ATTENTION: If an Upload command is not performed during Module
Discovery, any preconfigured E300 relay configuration data is not retained when
adding an E300 relay online to a ControlLogix project.

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
