Example 3: Optimizing Measurements at Low Power Levels Measurement Examples
7-10 PN: 10585-00001 Rev. P ML2437A/38A OM/PM
Automatic Low Level averaging smooths the display but only if the reading is
comparatively stable. The default factory setting is LOW and will take out fluctuations
of +
0.01 dB.
To change this setting to MEDIUM (+
0.02 dB), HIGH (+ 0.05 dB) or to turn it OFF,
press [LOW LEVEL].
Typical display for measurement of low power levels.
Figure 7-16.
Figure 7-17.
