ML24XXA Quick Reference
C-4 PN: 10585-00001 Rev. P ML2437A/38A OM/PM
GPIB Trigger Functional Group Commands
Profile Setup Functional Group Commands
Table C-8. GPIB Trigger Functional Group Commands
Command Function
GT0 Set to ignore GET command
GT1 Set 'GET' command to TR1 type trigger
GT2 Set 'GET' command to TR2 type trigger
TR0 Trigger hold mode
TR1 Trigger immediate
TR2 Trigger with a settling delay
TR3 Trigger free run
Table C-9. Profile Setup Functional Group Commands
Command Function
CURLK(?) Link cursors in profile mode
DTRGD(?) Display Trigger Delay
GRAVG(?) Average between profile cursors
GPRST Reset min/max graph
GRCP(?) Connect points on profile
GRDATA(?) Display Graph Data
GRFS(?) Profile Reference line state
GRMD(?) Profile and Power vs. Time Mode Channel
Selection
GRPIX(?) Profile type
GRPRD(?) Profile data collection period
GRPTP(?) Graph Pre-trigger Percentage
GRSWP(?) Sweep to Sweep averaging
GRSWR Reset Profile Sweep to Sweep Averaging
GRTMM(?) Profile Min/Max tracking mode
GRYB(?) Set profile Y-axis bottom scale
GRYT(?) Set profile Y-axis top scale
