System Menu Front Panel Operation
5-32 PN: 10585-00001 Rev. P ML2437A/38A OM/PM
Print [PRINT]
This selection prints the screen and various operational settings through the rear panel
printer port.
Battery
Controls battery setup when the optional battery pack is installed.
AUTO [BAUTS]
Enables or disables the automatic power off feature. Automatic power off can be used to
conserve battery power when operating from the internal battery.
TIME [BAUTT]
When operating from the internal battery, Time sets the number of minutes that the
instrument will run before powering off in absence of any key activity. Enter a value of
10 to 240 minutes.
Figure 5-7. Sample ML2430A Series Printout
ANRITSU Power Meter ML2437A s/n: 97180010
Firmware: 2.02
Sensor A: NOT FITTED
Sensor Measurement Setup
Measurement Channel Setup
Readout
Measurement mode
Cal factor
Averaging mode & number
Low level averaging
Offset type & value
Settle % per reading
Range hold
Sensor zeroed
Trigger source
Trigger sample delay
Trigger gate width
Trigger arm
Measured value
High limit
Low limit
Limits test
A:
Default
Frequency (50.00MHz)
Auto
Low
Off
0.10%
Off
No
1: (A) 2: OFF
1:
Continuous
1.00ms
20.00ms
Blanking OFF
------
Off
Off
Off
