Anritsu ML2437A - Appendix C: GPIB Quick Reference; ML24 XXA Quick Reference

ML2437A/38A OM/PM PN: 10585-00001 Rev. P C-1
Appendix C — GPIB Quick Reference
This appendix contains quick reference tables for all supported commands. Native mode
commands are sorted by functional group.
C-1 ML24XXA Quick Reference
The following tables reference ML24XXA (native) mode commands. A command followed by a
(?) indicates that there is an equivalent query command for that function.
BNC Functional Group Commands
Calibration Functional Group Commands
Channel Functional Group Commands
Table C-1. Functional Group Commands
Command Function
IBBLP Blanking active TTL level
OBACM(?) AC modulation output polarity
OBCH(?) BNC output port channel configuration
OBDSP(?) BNC analog output display stop value
OBDST(?) BNC analog output display start value
OBMD(?) BNC output mode select
OBPL(?) BNC pass/fail pass level
OBVSP(?) BNC analog output stop voltage scale
OBVST(?) BNC analog output start voltage scale
OBZL(?) BNC RF blanking output level
Table C-2. Calibration Functional Group Commands
Command Function
CAL Calibrate the selected sensor to 0 dBm
RFCAL(?) Turn RF reference calibrator ON or OFF
VZERO Zero the BNC input connector
ZERO Zero the sensor
Table C-3. Channel Functional Group Commands
Command Function
CHCFG(?) Channel input configuration
CHRES(?) Set channel decimal point resolution
