GPIB Operation ML4803A Emulation Commands
ML2437A/38A OM/PM PN: 10585-00001 Rev. P 8-85
8-10 ML4803A Emulation Commands
This section provides an alphabetical listing of the GPIB commands (mnemonics) used to
program the Model ML243xA Power Meter in ML4803A mode. The emulation mode can be
set through the front panel SYSTEM > more > more > Rear panel > GPIB > MODE menu or
through the GPIB command EMUL.
All ML4803A GPIB commands that use parameters must not
have a space between the
command header and the parameter. Multiple parameters must be separated by semicolons.
Multiple commands may be sent on the same line, but must be separated by spaces.
The format for ML4803A GPIB commands is:
<command header><parameter 1>;<parameter n>;...
The end of the command text must be terminated with a line feed character (0Ah, decimal 10)
or a GPIB End of Transmission State (EOI), or both.
The ML4803A has an array of memory addresses that each hold a structure of four values;
Frequency, Cal factor, Offset, and Reference. The data held for an entered frequency is not
automatically applied, but only applied if that memory address is called. The frequency value
is only a reference to the operator for which the cal factor and other data is relevant. These
memory address sets of data are only available via the GPIB in ML4803A emulation mode.
SRQs
The startup and default mode of operation for the ML4803A is to set an SRQ off then on again
for every reading when available. This has the affect of pulsing the SRQ line very quickly and
would make it very difficult to use the ML4803A with other devices on the GPIB bus that
wish to communicate via SRQs. These SRQs can be turned off temporarily by the ‘SRQ0’
command. The SRQs will start again as soon as any data is requested from the ML4803A.
Status Byte
The following table and diagram define the Status Byte.
Table 8-6. Status Byte
Bit Definition Description
Bit 0 Zero execution Bit set during zeroing. When
zeroing is complete the bit is
cleared and the ODR bit and
RQS bits are reset.
Bit 1 Cal execution Bit is set during the Cal 0 dBm.
Bit 3 Output data ready ODR bit is cleared and set for
every reading when made.
This is done in sync with the
RQS bit giving an SRQ.
Bit 5 Command error Set on receiving an
unrecognized command. The
bit is cleared by reading the
status byte.
