Sensor Menu Front Panel Operation
5-12 PN: 10585-00001 Rev. P ML2437A/38A OM/PM
TABLE [OFFTBL, OFFTBR, OFFTBU, OFFVAL]
Select the offset table number (1-5) when Offset TYPE is set to Table. When a table is
selected, additional soft keys become available:
Duty cycle
Applies a duty cycle to the selected sensor. An offset will be applied based on the entered
value.
SENSOR
Model ML2438A (dual channel) only. Used to select the sensor to be configured. Toggles
between sensor A and sensor B for all submenu functions.
STATE [DUTYS]
ON or OFF
DUTY [DUTYS]
Delete, Enter, or Cancel. An offset will be applied based on the entered value. For
example, specifying a duty cycle of 50 % will alter the displayed readings by
approximately +3.01 dB.
Rng Hold [RGH]
This function will toggle the sensor between holding the present operating range and Auto
Ranging. Auto Ranging automatically selects the best range to take the measurement.
If either sensor is auto ranging, this key will force both sensors to hold their present
operating ranges. If either sensor is held within an operation range, this key will force both
sensors to Auto Range.
EDIT: This will bring up all of the selected offset table’s entries, with their
associated frequencies and offsets. Select an entry and enter the
frequency and offset using the keypad.
CLEAR
[OFFCLR]:
When an offset table is selected, CLEAR will set all of the table’s
elements to zero.
Note
Rng Hold is not available when System > Setup > mode is set to Source Sweep. In
this mode, AUTO ranging is used.
