Example 7: Measuring Pulse Signals With a Duty Cycle Measurement Examples
7-18 PN: 10585-00001 Rev. P ML2437A/38A OM/PM
The following screen is displayed:
Figure 7-28.
Note
Note that box A in the top right hand corner of the screen now indicates that a Duty
Cycle percentage has been applied to the Sensor.
