GPIB Operation HP436A Emulation Commands
ML2437A/38A OM/PM PN: 10585-00001 Rev. P 8-101
The table below describes the HPIB output data format.
Table 8-7. HPIB Output Data Format
Definition Character
Status ASCII Decimal
Measured value valid P 80
Watts mode under range Q 81
Over range R 82
Under range dBm or dB (Rel) mode S 83
Power Sensor Auto Zero loop enabled; range 1 under range T 84
Power Sensor Auto Zero loop enabled; not range 1 under range U 85
Power Sensor Auto Zero loop enabled; over range V 86
Range
1 (Most sensitive) I 73
2J74
3K75
4L76
5 (Least sensitive) M 77
Mode
Watt A 65
dB Rel B 66
dB ref C 67
dBm D 68
Sign of Measured Value
Space (+) SP 32
- (minus) _ 45
Measured Value Digits
0048
1149
2250
3351
4452
5553
6654
7755
8856
9957
