HP437B Emulation Commands GPIB Operation
8-104 PN: 10585-00001 Rev. P ML2437A/38A OM/PM
Figure 8-10. IEEE 488.2 Standard Status Structures
Logical OR
Standard
Event Status Enable
Register
*ESE <NRf>
*ESE?
Standard
Event Status Register
*ESR?
Power On User Request Command Error Execution Error Device Dependent Error Query Error Request Control Operation Complete
76543210
76543210
Output Queue
Queue
not empty
6
MSS
RQS
Logical OR
Service
Request
Generation
read by Serial Poll
read by *STB?
Status Byte Register
Service Request
Enable Register
*SRE <NRf>
*SRE?
7
ESB MAV
3210
7 543210
