15. Liquid cooling circuit
2
2
4
3
4
3
Image 15-36
Pump, fixation
7. C lean the pum p house w ith a clean soft cloth. Use cotton swabs to clean the bearing of the pump house.
8. S lide the p ump hous e w ith hose on the new pump motor.
Caution: Make sure that the new Pump motor is provide with a new rotor and a new sealing ring.
Image 15-37
Pump house, installation
9. Fas ten the four screws (reference 1) of the pump house crossw is e using a PH2 Phillips screwdriver.
1
1
1
1
Image 15-38
Pump house, fixation
10.R econnect th e w ire un it of the pump.
R5905312 HDF W SERIES 24/01/2013
261
